Planetary Milling Jars
>
|
| Place of Origin | Hunan, China |
| Brand Name | Kingda |
| Model Number | 50ML-3L |
Pot/Jar Ball Mill Alumina Ceramic Crucible Hot Sale Lab Experiment Planetary Use 50ml -5000ml Jar 100*100*100 95% Al2o3 2000 Mpa
Hot Sale Lab Experiment Planetary Ball Mill use 50ml-5000ml alumina ceramic mill pot/jar
Polished alumina ceramic jars. These jars are used whenever small quantity of samples need to be grinded. They are extensively applied to in the fields of Paint, Ink, Geology, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry, Medicine, Environmental Protection and so on. Each jar set includes grinding jar, jar lid, rubber sealing gasket and different sizes of mixed alumina ceramic grinding balls.
|
Composition (%) |
Specific Gravity (G/CM3) |
Hardness (Mho’s)
|
Capacity (ml) |
|
Al2O3:≥ 99.0 |
≥ 3.8 | 9 |
0.05;100;250; 500;1000;1500;2000;3000 |
| Jar Volume | OD (mm) | ID (mm) | Total Height (mm) |
| 50ml | 55 | 38 | 67 |
| 100ml | 65 | 50 | 75 |
| 250ml | 92 | 74 | 88 |
| 500ml | 100 | 84 | 118 |
| 1000ml | 128 | 108 | 150 |
| 1.5L | 132 | 112 | 175 |
| 2.0L | 158 | 138 | 162 |
| 3.0L | 158 | 138 | 220 |
|
Grinding Jar Volume
|
100ml
|
250ml
|
500ml
|
1000ml
|
|
Compatible Ball Weight
|
66g
|
165g
|
330g
|
660g
|
|
Φ5mm grinding balls (0.25 g/pc)
|
106 pcs
|
300 pcs
|
||
|
Φ10mm grinding balls (1.99 g/pc)
|
20 pcs
|
76 pcs
|
50 pcs
|
100 pcs
|
|
Φ15mm grinding balls (6.72 g/pc)
|
4 pcs
|
30 pcs
|
59 pcs
|
|
|
Φ20mm grinding balls (15.92 g/pc)
|
3 pcs
Grinding Jar Volume
|
5 pcs
|
These values are just clues: the number of balls should be determined experimentally if necessary.
1.What's product your company supply?
A.We can supply yttrium stab.zirconia bead,cerium stab.zirconia bead,zirconia silicate bead,high alumina ball, agate ball, ball mill grinding jar, tungsten carbide ball, zirconium powder,ceramic structual elements etc.
2. Q: What is your MOQ?
A: 1KG. We accept smaller quantity but price is higher.
3. Q: Can you provide free samples?
A: Yes, the buyers just afford shipping cost .
4. Q: What is your production time for bulk order?
A: 7~30 days, according to order quantity.
5. Q: What is your normal package?
A: Woven bag or barrel ,drum,carton box and pallet.
6. Q: What is your payment term?
A: T/T 30%-70% Deposit, balance against copy of B/L.
L/C at sight,Western Union, paypal,Visa,etc
