Product Description————————
1. Zirconia material has advantages of high hardness, high strength, high tenacity, high wear resistance and good corrosion resistance which is widely applied in fields of ceramics, fire proofing material, machinery, electronic, photics, Aeronautics and astronautics, biology and chemicals and etc.
2. Zirconia griding mill jar is particularly suitable for vertical stirring mill, horizontal rolling mill, vibration mill, and various high-wire-speed sanding stick pins, etc
3.We also produce zirconia, alumina,agate and tungsten carbide jar for Retsch ,Fristch lab ball mill, such as Retsch PM100,PM200,PM400 planetary ball mill, Retsch disc vibratory ball mill RS200 ,Mixer Mill MM 400 and Fritsh P6,P7,etc.
Application————————
1. Particularly suitable for vertical stirring mills, horizontal roller ball mills, vibrating mills and various high linear, speed pin- type sand mills.
2. For wet or dry ultrafine dispersion and grinding of pastes and powders without contamination.
3. Perfect grinding mill jar with good flatness, smooth surface, bright,high density and high strength.
4. Wear and corrosion resistant product: coating, textile, pigment, dyeing.
5. High strength, high tenacity product: magnetic material, piezoelectric ceramics, dielectric ceramics.
6. Pollution prevention: medicine, food, cosmetics.
7. Ceramics: electronic ceramics, refractory ceramics, structural ceramics.
Properties and technique parameters————————
| Performance |
Unit |
Parameter |
| Component |
Wt% |
95%Zro2+5%Y2O3 |
| Density |
g/cm3 |
6.0-6.05 |
| Hardness |
Moh's |
9 |
| Elasticity Modulus |
GPa |
200 |
| Thermal conductivity |
W/m.k |
3 |
| Coefficient of thermal Expansion |
10*10-6/ºC(20-400) |
9.6 |
| Crush Strength |
KN |
≥20(φ7mm) |
| Bending toughness |
MPam1/2 |
8
|
VOLUME OF JAR
| Volume of Jar |
Inner Diameter
(mm) |
External Diameter
(mm) |
Inner Depth
(mm)
|
Height of without lid
(mm)
|
Total Height
(mm) |
Weight (g) |
| 50ml |
38 |
55 |
52 |
60 |
67 |
610 |
| 100ml |
50 |
65 |
58 |
66 |
75 |
835 |
| 250ml |
74 |
92 |
70 |
78 |
88 |
1760 |
| 500ml |
84 |
100 |
100 |
108 |
118 |
2300 |
| 1L |
108 |
128 |
128 |
138 |
150 |
4780 |
| 2L |
138 |
158 |
140 |
150 |
162 |
6750 |
| 3L |
138 |
158 |
198 |
208 |
220 |
8400 |
| Remarks:1. Size deviation within ±2mm； 2. Weight deviation within ±0.2KG |
Features————————
Exceptional Hardness:
Zirconia grinding beads are known for their exceptional hardness, providing superior wear resistance during grinding processes. This characteristic ensures a longer lifespan and consistent performance in various applications.
High Density:
With high density, Zirconia beads generate significant impact forces during grinding, facilitating efficient particle size reduction and dispersion. This makes them effective in achieving fine and uniform grinding results.
Chemical Inertness:
Zirconia is chemically inert, preventing reactions with most chemicals. This inertness ensures the purity of the samples being ground, making Zirconia grinding beads suitable for applications with stringent purity requirements.
Corrosion Resistance:
Zirconia exhibits excellent corrosion resistance, ensuring durability and stability in corrosive environments. This makes Zirconia grinding beads suitable for a wide range of industrial applications.
Package & Shipping————————
Package Type:
PE Form + Cartons / Woodern cases;
Can be dispatched according to customr's requirement
Port:
Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port.
Delivery time:
Within 3-7 working days from the date of payment receipt
Factory————————
Product Flow————————
FAQ————————
1.Q: What is the size in your products?
A: Our common size is 50ml-3L. We can also produce according to your request.
2.Q: What is your terms of delivery?
A: FOB, CFR, CIF.
3.Q: Can you accept small quantity sample order before production?
A: Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.
4.Q: What is your production time?
A: Generally, it will take 3-15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
5.Q: What is your terms of payment?
A: T/T 30% as deposit, 70% balance against the copy of original B/L. Or 100% L/C at sight. We'll show you the photos of the products and the copy of original B/L before you pay the balance.
Our Service————————
1. We can produce other grinding balls as your need.
2. We test all the goods before delivery.
3. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
4. If you have any questions, please contact with us without any hesitation, we will reply you in 12 hours.
ABOUT KINGDA————————
1.KINGDA CERAMIC MATERIALS CO.,LTD is a manufacturer of the Grinding Media Ball, Grinding Jars, Zirconium Dioxide, Zirconia structures, etc.
2. "Quality Is in the First Position forever", we have gained a high reputation and good recognition from a lot of domestic and overseas customers such as University of Oxford, Lough borough University, Peking University, Tsinghua University, etc.
3. We promise that we would make great efforts to provide high quality grinding products and best services for all customers in the coming years.
4. Nowadays,KINGDA CERAMIC MATERIALS CO.,LTD has gained great reputation from our business partners. We will continue to contribute the best to realize mutual benefit and sustainability.
5. We appreciate your interest and support in the efforts and passion of KINGDA CERAMIC, the company of Human Technology.
