Home > Products > Jar Mill >
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding

Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding

Laboratory Planetary Ball Mill Machine

Alumina Jar Planetary Ball Mill Machine

Place of Origin:

Hunan, China

Brand Name:

Kingda

Certification:

CE ISO

Model Number:

KDGQM

Contact Us
Request A Quote
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding
Product Details
Model NO.:
Planetary Ball Mill
Working Style:
High-speed Universal
Disc Diameter:
180mm
Variable Speed:
With Variable Speed
Product Name:
Vertical Planetary Ball Mill
Weight:
55kg
Voltage:
220V-50Hz
Core Components:
Bearing, Pump, Gear
Power Supply:
110V-60Hz Or 220-50Hz 0.32kw
Rotation Speed:
90-870 Rpm
Working Position:
4 Working Positions
Matchable Jar Volume:
50ml/100ml
Feed Size Of Material:
Less Than 10mm
Power:
0.75kw
After-Sales Service Provided:
Free Spare Parts, Field Installation...
After Warranty Service:
Video Technical Support, No Service, Spare Parts
Warranty:
1 Year
Product Type:
Powder
Output Size (Mesh):
45 - 535 Mesh
Transport Package:
530*300*340 Mm
Specification:
0.2L-16L
Trademark:
KINGDA
Origin:
Hunan, China
HS Code:
8479909090
Supply Ability:
50000 Pieces/Year
Type:
Disc Grinder
Power Source:
Electricity
Object:
Milling Cutter
Application:
Laboratory
Disc(Wheel) Type:
Grinding Disc
Material:
Steel
Customization:
Available | Customized Request
Highlight:

Laboratory Planetary Ball Mill Machine

,

Alumina Jar Planetary Ball Mill Machine

Payment & Shipping Terms
Minimum Order Quantity
1 Set
Price
Negotiable
Packaging Details
PE Foam + Cartons / Wooden cases
Delivery Time
3-7 Days
Payment Terms
L/C,D/A,D/P,T/T,Western Union
Supply Ability
1000 Set / Month
RELATED PRODUCTS
Good price Kingda 0.72KW/220V Lab Roll Ball Mill for Ultra-Fine Grinding with 1000 Mesh Output online Video

Kingda 0.72KW/220V Lab Roll Ball Mill for Ultra-Fine Grinding with 1000 Mesh Output

Get Best Price
Good price Hunan Kingda Machine 2-5L SS Mill Jar High Efficient Lab Roller Ball Mill Machine for Lab Research online Video

Hunan Kingda Machine 2-5L SS Mill Jar High Efficient Lab Roller Ball Mill Machine for Lab Research

Get Best Price
Good price Variable speed control – Wide speed range for different materials such as ceramics, minerals, batteries, and inks. online Video

Variable speed control – Wide speed range for different materials such as ceramics, minerals, batteries, and inks.

Get Best Price
Good price Laboratory Compact Jar Mill Ball Milling Machine 220V Roller Ball Mill with Multi Stations Powder Grinding online Video

Laboratory Compact Jar Mill Ball Milling Machine 220V Roller Ball Mill with Multi Stations Powder Grinding

Get Best Price
Contact Us
15367874686
sales@kingdacera.com
Contact Now
Product Description
Laboratory Planetary Ball Mill Machine with Alumina Jar and Customizable Grinding Disc
Planetary Ball Mill Industrial For Production Nano Powder
Vertical planetary ball mill is a necessary device for high-tech materials mixing, fine grinding, sample preparation, new product development and small batch production. This compact unit features high efficiency, low noise operation and is ideal for R&D institutions, universities, and enterprise laboratories.
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 0
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 1
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 2
Key Features
  • Four ball grinding tanks installed on one turnplate for simultaneous processing
  • Capable of dry or wet method grinding with minimum granularity of 0.1 micron
  • Variable-frequency control with programmable speed regulation
  • Safety switch prevents operation when cover is open
  • Timing functions with multiple operation modes for efficiency
  • Low center of gravity design ensures stable performance
Technical Specifications
Model Specification Capacity Quantity
XQM-0.4L 0.4L 50-100ml 4 mill tanks
XQM-1L 1L 50-250ml 4 mill tanks
XQM-2L 2L 50-500ml 4 mill tanks
XQM-4L 4L 50-1000ml 4 mill tanks
XQM-8L 8L 0.5-2L 4 mill tanks
XQM-12L 12L 1-3L 4 mill tanks
XQM-16L 16L 1-4L 4 mill tanks
Applications
  • Wet or dry ultrafine dispersion and grinding of pastes and powders
  • Materials processing: coating, textile, pigment, dyeing
  • High-strength materials: magnetic material, piezoelectric ceramics
  • Pollution prevention industries: medicine, food, cosmetics
  • Ceramics production: electronic ceramics, refractory ceramics
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 3
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 4
Package & Shipping
Package Type: Carton or plywood case + foam
Port: Shanghai, Guangzhou, Tianjin, Qingdao
Delivery Time: Within 15 working days from payment receipt
Frequently Asked Questions
Q: What is your smallest model for laboratory use?
A: The XQM-0.4A model (53×30×34cm, 26kg) is our smallest unit, with capacity options up to 100L available.
Q: What are your delivery terms?
A: We offer FOB, CFR, and CIF terms.
Q: Do you accept sample orders?
A: Yes, we provide samples for testing with customer covering courier costs.
Our Service Commitment
  • Custom grinding ball production available
  • Comprehensive pre-delivery testing
  • 12-hour response time for inquiries
  • Long-term technical support
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 5
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 6
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 7
About Our Company
HUNAN JINGSHENGDA CERAMIC TECHNOLOGY CO.,LTD specializes in manufacturing grinding media, zirconium products, and ceramic solutions. Our commitment to quality has earned recognition from prestigious institutions worldwide including University of Oxford and Tsinghua University. We continue to innovate while maintaining our core values of mutual benefit and sustainability.
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 8
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 9
Laboratory Planetary Ball Mill with 4 Working Positions 220V-50Hz Power and 0.75kw Motor for High Efficiency Grinding 10
