Name: XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation
Brand: Hunan Jingshengda Ceramic Technology Co., Ltd
SKU: XQM-2L-TS
Price: 2.00 USD
Availability: InStock

Home > Products > Planetary Ball Mill >

XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation

750W programmable planetary ball mill

touch screen PLC control ball mill

nano powder grinder for sample preparation

Place of Origin:

Hunan, China

Brand Name:

Kingda

Certification:

CE, ISO 9001:2015

Model Number:

XQM-2L-TS

Request A Quote

Product Details

Capacity:

2L (500ml X 4 Jars)

Motor Power:

750W

Speed Range:

0-670 RPM

Control System:

7-inch Touch Screen HMI + PLC

Program Memory:

10 Grinding Recipes, Multi-Step

Real-Time Monitoring:

Speed, Time, Temperature, Running Status

Voltage:

220V/380V 50Hz/60Hz Selectable

Feed Size:

≤10mm

Discharge Size:

0.1μm Minimum

Jar Material Options:

Zirconia, Alumina, Agate, Stainless Steel, Tungsten Carbide

Highlight:

750W programmable planetary ball mill

touch screen PLC control ball mill

nano powder grinder for sample preparation

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

USD 1,800-3,200 / Set

Packaging Details

Export-grade wooden case with high-density foam padding, vacuum-packed main unit, shock-proof corner protection

Delivery Time

7-15 working days

Payment Terms

T/T,L/C,Western Union,PayPal

Supply Ability

500 Sets per Month

0.2-100L Horizontal Planetary Ball Mill 4 Stations Continuous 72h Nano Powder Machine for Industrial Use

Get Best Price

Video

Full Directional 360 Degree Planetary Ball Mill 4 Jars High Uniformity Nano Grinder for Advanced Material Research

Get Best Price

Video

4L Vertical Lab Planetary Ball Mill 4 Zirconia Grinding Jars 0.1μm Nano Output Enterprise Laboratory Equipment

Get Best Price

Video

XQM-0.4L Variable Frequency Drive Planetary Ball Mill with 0.4L Capacity and 0.1μm Discharge Size for Nano Powder Grinding

Get Best Price

Contact Now

Product Description

XQM-2L Touch Screen PLC Control Planetary Ball Mill

The XQM-2L represents the next generation of intelligent laboratory grinding with its advanced 7-inch touch screen HMI and PLC control system. This programmable planetary ball mill enables automated multi-step grinding recipes with real-time parameter monitoring, delivering precision and repeatability for demanding nano powder synthesis and sample preparation applications.

XQM-2L Touch Screen PLC Control Planetary Ball Mill 750W Programmable Nano Powder Grinder for Sample Preparation

Intelligent Control System

7-Inch Touch Screen HMI

Intuitive full-color touch screen interface with graphical display of speed curves, temperature trends, and operational status for effortless parameter setting and monitoring.

PLC Programmable Control

Industrial-grade PLC controller supports up to 10 custom grinding recipes with multi-step programming: set different speeds, durations, and pause intervals for complex protocols.

Real-Time Parameter Monitoring

Continuous monitoring of rotation speed, grinding time, motor temperature, and running status with on-screen digital readouts and automatic fault alarm protection.

One-Touch Recipe Recall

Save and recall grinding programs instantly - ideal for laboratories running standardized SOPs across multiple operators and material batches.

Technical Specifications

Parameter	Specification
Model	XQM-2L-TS
Capacity	2L (500ml x 4 Jars)
Motor Power	750W
Speed Range	70-670 RPM
Control System	7-inch Touch Screen HMI + PLC
Program Memory	10 Grinding Recipes, Multi-Step
Voltage	220V/380V 50Hz/60Hz Selectable
Feed Size	≤10mm
Discharge Size	0.1μm Minimum
Transmission Ratio	1:2
Safety Features	Overload Protection, Emergency Stop, Door Interlock

Jar Material Compatibility

Zirconia (ZrO₂) Alumina (Al₂O₃) Agate Stainless Steel 304 Tungsten Carbide (WC) Nylon PTFE

Applications

Automated nano powder preparation with programmable multi-step grinding protocols
High-throughput sample preparation for XRD, XRF, and spectroscopic analysis
Mechanical alloying with precise control over milling energy and duration
Quality control laboratories requiring standardized, repeatable grinding SOPs
Battery material synthesis: cathode and anode powder processing
Pharmaceutical milling with documented process parameter traceability

Kingda delivers intelligent laboratory ball mill solutions trusted by research institutions and industrial labs worldwide. All our planetary ball mills feature CE certification and a one-year comprehensive warranty. Contact us now to discuss your grinding requirements and receive a tailored quotation.
