Home > Products > Jar Mill >
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency.

Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency.

Lab Grinding Rotary Ball Mill

15L Jars Rotary Ball Mill

8*5L Rotary Ball Mill

Place of Origin:

Hunan, China

Brand Name:

KINGDA

Certification:

CE ISO

Model Number:

GQM-8*5L

Contact Us
Request A Quote
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency.
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency.
Product Details
ProdJar Rolling Milluct Name:
Rolling Ball Mill
Applicable Industries:
Lab Research
Weight (KG):
106 KG
Output (kg/h):
1-14 Kg/h
Feeding Size (mm):
≥5mm
Output Size (mesh):
1000 Mesh / 13µm
Volumn Of Matched Pot:
8*5L Jar
Warranty:
1 Year
After-sales Service Provided:
Video Technical Support
Highlight:

Lab Grinding Rotary Ball Mill

,

15L Jars Rotary Ball Mill

,

8*5L Rotary Ball Mill

Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
PE Foam + Cartons / Wooden cases
Delivery Time
15Day
Payment Terms
L/C,D/A,T/T,Western Union
Supply Ability
1000 set / Month
RELATED PRODUCTS
Good price Kingda 0.72KW/220V Lab Roll Ball Mill for Ultra-Fine Grinding with 1000 Mesh Output online Video

Kingda 0.72KW/220V Lab Roll Ball Mill for Ultra-Fine Grinding with 1000 Mesh Output

Get Best Price
Good price Hunan Kingda Machine 2-5L SS Mill Jar High Efficient Lab Roller Ball Mill Machine for Lab Research online Video

Hunan Kingda Machine 2-5L SS Mill Jar High Efficient Lab Roller Ball Mill Machine for Lab Research

Get Best Price
Good price Variable speed control – Wide speed range for different materials such as ceramics, minerals, batteries, and inks. online Video

Variable speed control – Wide speed range for different materials such as ceramics, minerals, batteries, and inks.

Get Best Price
Good price Laboratory Compact Jar Mill Ball Milling Machine 220V Roller Ball Mill with Multi Stations Powder Grinding online Video

Laboratory Compact Jar Mill Ball Milling Machine 220V Roller Ball Mill with Multi Stations Powder Grinding

Get Best Price
CONTACT US
15367874686
sales@kingdacera.com
Contact Now
Product Description

Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency.
Product Description
Kingda Mixing Small Alumina Ceramic Grinding High Energy Jar Roller Ball Mill Lab Planetary Use
  • Easy Cleaning: Designed for easy cleaning, facilitating swift maintenance and minimizing downtime between experiments.
  • Small Lab Size: Compact size ideal for small laboratory spaces, allowing efficient planetary grinding experiments.
  • Versatile Grinding: Suitable for various materials, enabling planetary grinding of samples for different research applications.
  • Precision Performance: Delivers precise and uniform grinding results, ensuring reproducibility and reliability.
  • User-Friendly Design: Intuitive controls and ergonomic design for ease of operation.
  • Planetary Grinding Use: Specifically designed for planetary grinding applications for fine particle size reduction.

Working Principle
The working principle of a laboratory rotary drum ball mill revolves around the movement and friction within the drum:
  • Loading Samples and Media: Solid samples and grinding media (typically metal balls) are placed into the drum.
  • Drum Rotation: The drum rotates, causing samples and media to move within.
  • Friction and Collision: Friction and collisions between samples and media break and mix particles.
  • Gravity Action: Movement downward along the drum wall enhances friction and collision.
  • Continuous Cycling: This cyclic process continues until desired particle size and mixing consistency is achieved.

Specifications
Category Model No. Power Supply Rotate Speed Max Load Per Jar Dimensions & Net Weight
2 Work Positions GQM-2-5 220V-50Hz or 60Hz/0.75kw 50-410 rpm 35KGS 950*480*685mm 59KGS
GQM-2-15 220V-50Hz or 60Hz/1.1kw 40-365 rpm 80KGS 1130*550*690mm 80KGS
GQM-2-20 220V-50Hz or 60Hz/1.5kw 40-340 rpm 120KGS 1350*650*690mm 92KGS
4 Work Positions GQM-4-5 Single layer 220V-50Hz or 60Hz/0.75kw 50-410 rpm 35KGS 950*660*690mm 70KGS
GQM-4-5 Double layer 220V-50Hz or 60Hz/0.75kw 50-410 rpm 35KGS 950*480*870mm 92KGS
GQM-4-15 220V-50Hz or 60Hz/1.5kw 40-365 rpm 80KGS 1130*800*690mm 95KGS
GQM-4-20 380V-50Hz or 60Hz/2.2kw 40-340 rpm 120KGS 1350*820*690mm 122KGS
8 Work Positions GQM-8-5 220V-50Hz or 60Hz/1.5kw 50-410 rpm 35KGS 950*660*960mm 106KGS
GQM-8-15 380V-50Hz or 60Hz/2.2kw 40-365 rpm 80KGS 1130*800*960mm 152KGS

Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 0


Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 1

Features
  • Enhanced Grinding Efficiency: Precisely engineered roller design ensures thorough and uniform mixing.
  • Versatile Jar Compatibility: Accommodates various sizes of ball mill jars for different applications.
  • Consistent Results: Delivers reproducible results ideal for research and development.
  • Robust Construction: Durable drum and sturdy ball mill jar ensure longevity.
  • Easy Operation: Intuitive operation suitable for all experience levels.
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 2 Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 3

Accessories of Grinding Pots & Balls
Available grinding jars in full sizes:
Zirconia ball mill jar, alumina ball mill jar, Agate ball mill jar, Tungsten ball mill, hard metal mill jar and etc.
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 4

Package & Shipping
  • Package Type: PE Form + Cartons / Wooden cases; Can be dispatched according to customer's requirement
  • Port: Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port
  • Delivery time: Within 3-7 working days from the date of payment receipt
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 5

FAQ
1. What are the roll mill jars available in your products?
A: Our available roll mill jars are alumina / zirconia ceramic, nylon, stainless steel, tungsten carbide, PTFE, polyurethane and so on.
2. What is your terms of delivery?
A: FOB, CFR, CIF.
3. Can you accept small quantity sample order before production?
A: Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.
4. What is your production time?
A: Generally, it will take 3-15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
5. What is your terms of payment?
A: T/T 30% as deposit, 70% balance against the copy of original B/L. Or 100% L/C at sight. We'll show you the photos of the products and the copy of original B/L before you pay the balance.

Our Service
  • We can produce other grinding balls as your need.
  • We test all the goods before delivery.
  • We respect every customer as our friend and we sincerely do business and make friends with them.
  • If you have any questions, please contact with us without any hesitation, we will reply you in 2 hours.
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 6

ABOUT KINGDA
  • HUNAN KINGDA CERAMIC TECHNOLOGY CO.,LTD is a manufacturer of the Grinding Media Ball, Grinding Jars, Zirconium Dioxide, Zirconia structures, etc.
  • "Quality Is in the First Position forever", we have gained a high reputation from customers such as University of Oxford, Loughborough University, Peking University, Tsinghua University, etc.
  • We promise to provide high quality grinding products and best services for all customers.
  • KINGDA CERAMIC MATERIALS has gained great reputation from our business partners.
  • We appreciate your interest and support in the efforts and passion of KINGDA CERAMIC.
Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 7 Multi-station design – Supports 2/4/6 stations for simultaneous grinding and mixing, improving laboratory efficiency. 8
